Acro Mini 2P
Westire Acro Mini Series
Photocells
Photocells
Photocells
Photocells
Photocells
Clocks
& Outdoor Lighting Controls
Accuracy
The Acro Mini 2P photocell utilises a filtered silicon based ambient light sensor and microprocessor control. This accurate combination provides the best energy savings and reliable operation.
Longevity
Engineered in the EU with a 15 year design life and manufactured in-house using only high quality name brand components, the Acro series photocells are renowned in the industry for their unparalleled quality and reliability
Features & Benefits
- Sensor head is remote from the switching section.
- Light sensor can be mounted up to 1 meters from switching section.
- Rated for 400W HID or LED Luminaire (Max 5 amps).
- Unique fully encapsulated electronic circuitry and light sensor are completely impervious to humidity and moisture.
- Electronic design outperforms thermal controls.
- Designed to meet the needs of LED fixtures while still maintaining proven reliability for more traditional technologies.
- Energy efficient design with an average power consumption <0.25 watts.
- UV stabilised polycarbonate housing is rated and tested to IP 67.
- UV stabilised fully encapsulated M20 threaded remote light sensor.
- Sensor window designed to survive all types of outdoor conditions
- A full electrical and 48 hour operational burn-in test is performed on every unit before leaving the factory.
ROHS compliant
Specification
| Dimensions – Housing | Switching Housing: 55mm L x 33mm D x 30mm H 2.16” L x 1.3” D x 1.88” H Remote Sensor Head: |
| Warranty | 8 years standard. 10 years available on request. |
| Mains Supply Voltage | 200 – 260 Volts AC – 50/60 Hz. |
| Power Supply Consumption | Less than 0.25 Watt |
| Max Load | 10 Amps |
| Load Rating | 1.8KVA Ballast / 1000 Watts |
| Operating Temperature | -20° C to +80° C -4° F to +176° F |
| Enclosure Protection Rating | IP67 sealing properties. Fully encapsulated electronics in switching section and sensor head. Fully impervious to moisture. |
| Standards Compliance | Environmental RoHS, EN55015, EN61547, EN6100-3-2, EN6100-3-3, ETL UK 773, CSA 22.2. IS EN ISO 9002: 2015 ANSI C136.24 |
| Switch ‘On’ light levels | 10 to 120 Lux ± 0.025 1 to 11 fc ± 0.025 |
| Switching Ratio | 1:0.5 to 1:1.5 |
| Ambient Light Sensor | Color corrected photodiode + amplifier |
| Switching Time Delay | 25 Seconds or as specified |
| Switching Options | Dusk to Dawn. Part night option available. |
