Set 45
SOLAR TIME CLOCK
Photocells
Photocells
Photocells
Photocells
Photocells
Clocks
& Outdoor Lighting Controls
Accuracy
The Astro Time Switch can automatically adjust itself for Daylight Saving Time (BST/GMT) and leap year adjustments with up to 10 years of battery backup
Reliability
The Astro Time Switch incorporates the latest microcontroller technology and is designed to have a high level of immunity.
Features & Benefits
- Can be used where it is difficult to install a photocell control.
- Applications in internal lighting.
- 7-day programmability incorporating Dusk & Dawn Astronomical tracking set points with traditional time-based events.
- Channel 1 has solar based and 8 time-based switch points – Channel 2 has 12 time-based switch points.
- Automatic leap year adjustment.
- Local and remote load switch override feature.
- Up to 10 year battery backup.
- Universal power supply 85 to 265 VAC 50/60 Hz.
- Outputs are protected by 132 Joule M.
- Relay Assisted Triac (RAT) switch – reliable switching of reactive loads such as street lighting.
- Capable of switching reactive loads up to 10 A on each channel.
- Mountable on a 35mm symmetric DIN Rail for ease of installation.
- Latitude and Longitude of location can be programmed by the user.
- Security code program protection and tamper proof cover.
- Illuminated keypad and backlit LCD display.
Certifications
- EMC – Meets the essential requirements of Directive 2004/108/EC for Electromagnetic Compatibility
- LVD – Meets the requirements of the Low Voltage Directive 2006/95/ EC
Specification
| Dimensions | 90mm x 70 mm x 73mm HxWxD (4 modules wide as per DIN 43880) |
| Mounting | Symmetric 35 mm DIN Rail |
| Warranty | 3 years standard |
| Mains Supply | 85 volts to 350 volts AC – 50/60 Hz |
| Output | 2 channels – Relay Assisted Triac (RAT) 10 amp rated supply connected (20 amp Device Max) |
| Connections | 4mm² max conductor size (12 AWG) |
| Standards Compliance & Certifications | Meets the essential requirements of Directive 2004/108/EC forElectromagnetic Compatibility
Meets the requirements of the Low Voltage Directive 2006/95/EC |
| Operating Temperature | -10° C to 45° C 14° F to 131° F |
| Enclosure Protection | IP20 , Flame Retardant Plastic with transparent protective cover |
| Battery Backup | 10 years @ 20° C – Internal lithium battery |
| Manual Overide | Manual overide button (MAN key) Momentary dry contact teminals (Normally Open) |
| Time Accuracy | ± 1 second per day @20˚C |
| Product Type | Electronic 1.Y.T., Software Class A. Not suitable for controlling loads where secure disconnection during conditions of mains abnormality is essential to safety. |
